Switch de Red Ruckus ICX 7550-48P-E2
Promo Online 🔥
Descripción:
Sobre este producto
- 📡 Switch apilable de gama media diseñado para conectividad cableada en el borde de la red para access points Wi-Fi
- 🔌 48 puertos 10/100/1000 con PoE+ más 2 puertos 40 Gigabit QSFP+ (uplink/stacking)
- ⚡ Presupuesto PoE+ de 2000 W para despliegues de campus exigentes
- 🧠 Capa 3 (L3), administrado, con flujo de aire front to back
- 📈 Rendimiento, flexibilidad y escalabilidad para escenarios de campus, formato rack-mountable
| Característica | Detalle |
|---|---|
| Marca | Ruckus |
| Línea de producto | Ruckus ICX |
| Modelo | 7550-48P-E2 |
| Fabricante | Ruckus Wireless |
| Flash Memory Installed | 4 GB |
| RAM instalada | 4 GB |
| Advanced Switching | Layer 3 |
| Estándares | IEEE 802.1ab (LLDP), IEEE 802.1ae, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Características | 3 fans, 802.1x authentication, Access Control List (ACL) support, Authentication, Authorization and Accounting (AAA), Auto-uplink (auto MDI/MDI-X), BOOTP support, BPDU Guard, Change of Authorization (CoA), Class of Service (CoS), Denial of Service (DoS), DHCP server, DHCP snooping, Digital Optical Monitoring (DOM) support, Dynamic VLAN Support (GVRP), Encapsulated Remote SPAN (ERSPAN), Flexible authentication, Flow control, Full duplex capability, IGMP snooping, In-Service Software Upgrade (ISSU), Inter-Packet Gap (IPG) adjustment, IPv4 support, IPv6 support, Link Fault Signaling (LFS), LLDP support, LLDP-MED, Long-Distance stacking (LD-VCStack), MAC address authentication, MAC address filtering, MAC based VLAN, MAC Learning Disable, MACsec support, Media Access Control Security (MACsec), Metro Ring Protocol (MRP) support, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Multiple VLAN Registration Protocol (MVRP), Neighbor Discovery Protocol (NDP), Network Timing Protocol (NTP), OpenFlow support, Per-VLAN Rapid Spanning Tree (PVRST), Per-VLAN Spanning Tree (PVST), Per-VLAN Spanning Tree Plus (PVST+), PIM-SM snooping, Port Loop Detection, Port mirroring, Precision Time Protocol (PTP), Private VLAN, Protected ports, Q-in-Q tunneling, Quality of Service (QoS), Remote Fault Notification (RFN), Remote Switch Port Analyzer (RSPAN), Root Guard, Secure Copy (SCP), sFlow, SmartZone, Strict Priority (SP), Syslog support, Telnet client, Telnet server, Uni-Directional Link Detection (UDLD), Virtual Cable Test (VCT) technology, Virtual Extensible LAN (VXLAN), Virtual Switch Redundancy Protocol (VSRP) support, VLAN support, Voice VLAN, Web authentication, Weighted Round Robin (WRR) |
| Form Factor (Hubs & Switches) | Rack-mountable |
| Jumbo Frame Support | 12288 bytes |
| Manageable | Yes |
| Max Units In A Stack | 12 |
| PoE Budget | 2000 watt |
| Ports | 48 |
| Power Over Ethernet (PoE) | PoE+ |
| Tipo de producto | Switch |
| Gestión remota | CLI, HTTP, HTTPS, SCP, SNMP 1, SNMP 2c, SNMP 3, SSH-2, TFTP |
| Routing Protocol | BGP, ECMP, OSPF, Policy-based routing (PBR), RIP, RIP-1, RIP-2, RIPng, Static IPv4 routing, Static IPv6 routing, VRRP |
| Stackable | Stackable |
| Subcategory | Network hubs and switches |
| Switching Type | Gigabit Ethernet |
| Expansion Slots | 1 expansion slot |
| Interfaces | 1 x 1000Base-T RJ-45 management, 1 x console (USB) Type C, 1 x console RJ-45, 2 x 40Gbit LAN QSFP+ uplink/stacking, 48 x 1000Base-T RJ-45 PoE+ - 90 W |
| Port Quantity | 48 |
| Port Type | 10/100/1000 (PoE+) |
| Ports Type (2nd) | 40 Gigabit QSFP+ (uplink/stacking) |
| Frequency | 50/60 hertz |
| Hot-Plug | Hot-plug |
| Power Consumption Operational | 1131.6 watt |
| Potencia | 1200 watt |
| Fuentes instaladas | 2 |
| Fuentes soportadas | 2 |
| Fuente redundante | Yes |
| Fuente redundante soportada | 1+1 |
| Encryption | AES |
| Humidity Range Storage | 5 - 95% (non-condensing) |
| Temp. máx. de operación | 113 degree Fahrenheit |
| Max Storage Temperature | 158 degree Fahrenheit |
| Temp. mín. de operación | 32 degree Fahrenheit |
| Min Storage Temperature | -40 degree Fahrenheit |
| MTBF | 304,125 Hours |
| Humedad de operación | 10 - 90% (non-condensing) |
| Airflow Direction | Front to back airflow |
| Authentication Method | RADIUS, Secure Shell v.2 (SSH2), TACACS, TACACS+ |
| Capacity | Maximum ports per trunk: 32, Multicast groups: 8192, Priority QoS queues: 48, PVLANs supported: 256, Spanning Tree Protocol instances: 512, Trunk groups: 256, Virtual interfaces (VLANs): 4095, VRF instances: 128 |
| Device Type | Internal power supply |
| Cantidad por empaque | 1 |
| Performance | Aggregate stacking bandwidth: 960 Gbps, Forwarding capacity: 309 Mpps, Switching capacity: 416 Gbps |
| Ports (2nd) Quantity | 2 |
| Alto | 1.7 inch |
| Altura (unidades de rack) | 1 |
| Weight | 15.65 lbs |
| Ancho | 17.3 inch |
| Profundidad | 16 inch |
| Color | Black |
| Certificado ENERGY STAR | No |
| Cumple EPEAT | No |
| TCO Certified | No |
Switch de Red Ruckus ICX 7550-48P-E2
Precio de oferta$18,121
Precio normal$22,288
