Tarjeta Madre ASUS A520M-PLUS TUF GAMING WIFI AMD AM4 microATX Motherboard
Descripción:
Sobre este producto
- 🛡️ Durabilidad TUF grado militar — componentes de calidad militar, solución de energía mejorada y un conjunto completo de opciones de refrigeración que garantizan estabilidad inquebrantable durante el juego.
- ⚙️ Chipset AMD A520 con socket AM4 — compatible con procesadores AMD Ryzen, en compacto formato microATX ideal para builds gaming accesibles y equilibrados.
- 🧠 DDR4 hasta 4866 MHz (OC) en 4 ranuras DIMM (128 GB máx., doble canal) — memoria de alto rendimiento con soporte para módulos de hasta 32 GB y amplios perfiles de overclock.
- 💾 M.2 NVMe y cuatro SATA con RAID — 1 x M.2 Socket 3 (M Key) para SSD NVMe (formatos 2242/2260/2280) y 4 puertos SATA 6Gb/s con soporte RAID 0, 1 y 10.
- 📶 WiFi 5 Realtek 8821CE + Bluetooth 5.0 — conectividad inalámbrica integrada (802.11ac) junto a LAN cableada Realtek Gigabit (10/100/1000 Mbps) para una conexión estable.
- 🔊 Audio Realtek ALC887/897 7.1 canales — sonido envolvente de alta definición para una experiencia inmersiva en juegos y multimedia.
| Característica | Detalles |
|---|---|
| Tipo de producto | Tarjeta Madre |
| Marca | ASUS |
| Modelo | RTUFA520MPLUSWF |
| UPC | 195553154284 |
| Packaging | Retail |
| Chipset | AMD A520 |
| BIOS | 128Mb AMI UEFI Bios |
| Manageability | PXE |
| AMD CPU Support | Ryzen |
| Socket | AM4 |
| ECC | Non-ECC; Non-Registered |
| Tipo de memoria | DDR4-2133 | DDR4-2400 | DDR4-2666 | DDR4-3200 | DDR4-2800 | DDR4-3000 |
| Memory Speeds Supported | 4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/3000/2800/2666/2400/2133 MHz |
| Memory Slots | 4 x 288pin DIMM |
| Memory Channel Support | Dual Channel |
| Max Memory Supported | 128GB |
| Maximum Memory Supported Per Slot | 32GB |
| Onboard Graphic Chipset | Requires CPU with Integrated Graphics |
| M.2 Port Type | 2242 | 2260 | 2280 |
| SATA Express | 1 x M.2 Socket 3 | M Key |
| SATA 6Gb/s | 4 |
| RAID Support | RAID 0 | RAID 1 | RAID 10 |
| Audio Chipset | ALC887/897 |
| Audio Channels | 7.1 |
| WiFi Support | Onboard WiFi |
| LAN Chipset | Realtek 1Gb Ethernet |
| LAN Speed | 10/100/1000Mbps |
| Wireless LAN Chipset | Realtek Wi-Fi 5 8821CE |
| Wireless Technology | 802.11b | 802.11g | 802.11a | Bluetooth v5.0 | WiFi 4 (802.11n) | WiFi 5 (802.11ac) |
| PCI Express 3.0 x16 | 1 |
| PCI Express x1 | 2 |
| Legacy Ports | 1 x PS/2 |
| LAN Ports | 1 x 10/100/1000 RJ-45 LAN |
| Audio Ports | 1 x 3.5 mm Microphone | 1 x 3.5 mm Line-In | 1 x 3.5 mm Line-Out |
| Buttons | BIOS Flashback |
| Specialty Ports | 2 x WiFi Antenna Ports |
| USB 2.0 | 2 x USB 2.0 (Type-A) |
| USB 3.1 | 4 x USB 3.2 (Gen 1 Type-A) |
| Video Connectors | 1 x DisplayPort 1.2 | 1 x VGA 15-pin | 1 x HDMI 2.1 |
| Headers | 1 x CPU Fan Header | 2 x CPU Fan Header |
| USB | 1 x USB 3.2 Gen 1 Type-A Header (2 Ports) | 2 x USB 2.0 Headers (3 Ports) |
| Other I/O | 2 x Addressable LED Headers |
| Power Connectors | 1 x 24-pin ATX Connector | 1 x 8-pin +12 V Connector |
| Conector ATX | 24-pin ATX Power Connector |
| Profundidad | 9.61 in. (244.00 mm) |
| Ancho | 9.61 in. (244.00 mm) |
| Factor de forma | microATX |
Tarjeta Madre ASUS A520M-PLUS TUF GAMING WIFI AMD AM4 microATX Motherboard
Precio de oferta$155
Precio normal$188
