Tarjeta Madre Gigabyte B860 DS3H WIFI6E Intel LGA 1851 ATX Motherboard
Descripción:
Sobre este producto
- 🔩 Socket Intel LGA 1851 compatible con procesadores Intel Core Ultra (Serie 2).
- 🧠 Chipset Intel B860 en formato ATX para builds de gaming y creación de contenido.
- 💾 DDR5 hasta 256GB en 4 slots, con perfiles OC de hasta 9066 MHz.
- ⚡ PCIe 5.0 x16 con PCIe UD Slot más cuatro ranuras PCIe 4.0 x1 y tres slots M.2.
- 📶 Wi-Fi 6E + LAN 2.5 GbE para conectividad rápida y estable.
- 🛠️ EZ-Latch Plug, Plus y Click para instalar GPU y SSD M.2 sin herramientas.
| Característica | Detalles |
|---|---|
| Tipo de producto | Tarjeta Madre |
| Modelo | Gigabyte B860 DS3H WIFI6E Intel LGA 1851 ATX Motherboard |
| Número de parte | B860DS3HWIFI6E |
| UPC | 889523046326 |
| Packaging | Retail |
| Chipset | Intel B860 |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | PnP 1.0a | WfM 2.0 | SM BIOS 2.7 | ACPI 5.0 | DMI 2.7 |
| Intel CPU Support | Core Ultra Processors |
| Socket | LGA 1851 |
| ECC | Non-ECC; Non-Registered | ECC; Non-Registered |
| Tipo de memoria | DDR5-5600 | DDR5-6400 |
| Memory Speeds Supported | 9066(O.C)/8800(O.C) /8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 5600 MHz |
| Memory Slots | 4 x 288pin DIMM |
| Memory Channel Support | Dual Channel |
| Max Memory Supported | 256GB |
| Maximum Memory Supported Per Slot | 64GB |
| Onboard Graphic Chipset | Requires CPU with Integrated Graphics |
| M.2 Port Type | 2280 | 22110 | 25110 | 2580 |
| SATA Express | 2 x M.2 Socket 3 | M Key |
| SATA 6Gb/s | 4 |
| RAID Support | RAID 0 | RAID 1 | RAID 5 | RAID 10 |
| Audio Chipset | Realtek |
| Audio Channels | 7.1 |
| WiFi Support | Onboard WiFi |
| LAN Chipset | Realtek 2.5Gb Ethernet |
| LAN Speed | 10/100/1000/2500Mbps |
| Wireless LAN Chipset | Intel Wi-Fi 6E AX211 |
| Wireless Technology | 802.11b | 802.11g | 802.11a | WiFi 4 (802.11n) | WiFi 5 (802.11ac) | WiFi 6 (802.11ax) | Bluetooth v5.3 | WiFi 6E (802.11ax) |
| PCI Express 4.0 x16 | 4 |
| PCI Express 5.0 x16 | 1 |
| Legacy Ports | 1 x PS/2 |
| LAN Ports | 1 x 10/100/1000/2500 RJ-45 LAN |
| Audio Ports | 1 x 3.5 mm Microphone | 1 x 3.5 mm Line-In | 1 x 3.5 mm Line-Out |
| Specialty Ports | 2 x WiFi Antenna Ports |
| USB 2.0 | 4 x USB 2.0 (Type-A) |
| USB 3.1 | 1 x USB 3.2 (Gen 2x2 Type-C) | 1 x USB 3.2 (Gen 2 Type-A) |
| Video Connectors | 1 x HDMI 2.1 | 1 x DisplayPort 2.1 |
| Headers | 1 x CPU Fan Header | 4 x System Fan Header | 1 x Water Pump Header |
| USB | 2 x USB 2.0 Headers (4 Ports) | 1 x USB 3.2 Gen 1 Type-A Header (2 Ports) | 1 x USB 3.2 Gen 1 Type-C Header (1 Port) |
| Other I/O | 3 x Addressable LED Headers |
| Power Connectors | 1 x 24-pin ATX Connector | 1 x 8-pin +12 V Connector |
| Conector ATX | 24-pin ATX Power Connector |
| Profundidad | 12.00 in. (305.00 mm) |
| Ancho | 9.61 in. (244.00 mm) |
| Factor de forma | ATX |
| What's in the Box | Motherboard, Manual, Antenna, 2x SATA Cables, I/O Shield, M.2 Rubber Pads |
Tarjeta Madre Gigabyte B860 DS3H WIFI6E Intel LGA 1851 ATX Motherboard
Precio de oferta$255
Precio normal$306
